Spesifikasi Teknis

Modul

• LED Type SMD2121
• Pixel Pitch 3.91 mm
• Module Resolution (W×H） 64*64=4096 Pixels
• HUB75
• Module Dimension 250mm×250mm×18mm
• Module Weight 0.49± 0.02kg

Optikal

• Support Single- dot Brightness Calibration
• White Balance Brightness 600 CD/m 2
• Standard Color Temperature (10000〜2000 )
• Beam Angle (Hor/Ver°） 140°/130°
• Contrast Ratio 3000 : 1
• Optical Sight Distance >4 m

Elektronik

• Max Power Consumption Of Module <25w
• Input Power <Max> 500W/m2
• Input Power <Typical> 150W/m2
• Power Supply Input Voltage AC90〜132V/AC186〜264V，Frequency47- 63Hz

Performa

• Frame Changing Frequency 60Hz
• Refresh Rate 1920 Hz
• Processing Depth 12~14 Bit
• Video Support 2K HD, 4K UHD

Lingkungan Kerja

• Storage Temperature / Humidity Range（℃ /RH） – 20℃~55℃ /10%~60%RH(No Condensation)
• Life Typical Value (HRS) 10000H
• Protecting Grade IP30
• Working Temperature/ Humidity Range（℃ /RH） – 20℃~+45℃ /10%~65%RH (No Condensation)
